COMPACT TILLER F510 K7 DEH

€2,000.00

Available on backorder

Category:


Description

Features

  • Multi-speed transmission (6 forward + 2 reverse)
  • Reversible ergonomic handlebars
  • Chain final drive for durability
  • Adjustable working depth and width
  • Suitable for gardens, vegetable plots and intensive soil preparation

Specifications

Specification F510 K7 DEH
Machine Type Compact Tiller
Engine Model GX160
Engine Type 4-Stroke OHV, Single Cylinder
Displacement 163 cc
Horsepower 4.8 HP
Rated Power 3.6 kW @ 3,600 RPM
Maximum Torque 10.3 Nm @ 2,500 RPM
Starting System Recoil
Fuel Tank Capacity 2.3 L
Engine Oil Capacity 0.60 L
Transmission Clutch Manual – Belt Tension
Transmission Constant Mesh Gearbox
Final Drive Chain
Forward Gears 6
Reverse Gears 2
Maximum Working Width 900 mm
Maximum Working Depth 330 mm
Rotor Speed (Forward) 122 rpm
Rotor Speed (Reverse) 32 rpm
Handle Type Reversible & Height Adjustable
Wheels Transport Wheels
Noise Level 97 dB(A)
Overall Length 1,585 mm
Overall Width 610 mm
Overall Height 865 mm
Dry Weight 50 kg
